Features
Engine
Agile 4 Cylinder Engine
Lifting Capacity
Heavy Duty 3500 Kg Lifting Capacity
Option Available
Available in Cabin/ ROPS
12F+12R Synchromesh Transmission
Jerk Free & Noise free Gear Shifting
Technical Specifications
Engine
| HP Category | 110 HP |
|---|---|
| No. of Cylinders | 4 |
| Displacement (ltr) | 4087 |
| Aspiration | Turbocharged with Intercooler |
| Bore/Stroke (mm) | 105/118 |
| Air Cleaner | Dry Air Cleaner |
| Rated RPM | 2200 |
| Max Torque | 430@1300 |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Double Clutch |
| Gearbox | 12F + 12R |
| Transmission | Synchromesh Shuttle Transmission |
Speed (Forward)
| Maximum Speed (Km/Hr) | 34.86 |
|---|---|
| Minimum Speed (Km/Hr) | 1.67 |
| Driver Seat | Mechanical Suspension |
Brakes
| Brakes | Wet Disk Brakes |
|---|---|
| Type of actuation | Hydraulically Assisted Brake |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Mechanical (Foot Operated) |
|---|
PTO
| PTO (RPM) |
540/540E 540/1000 (Optional) |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 110Ah |
|---|---|
| Alternator | 12V, 90Amp |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| Position Control | Standard |
|---|---|
| Automatic Draft Control | Standard |
| 3 Point Linkage | Cat-II |
| Lifting Capacity | 3500Kg |
| Auxiliary Hydraulic Circuit | 2DA |
Safety Switch
| Neutral Safety Switch | Standard |
|---|---|
| P.T.O Safety Switch | Standard |
| Clutch Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%) Approx
| Fuel Tank (Lit) | 117 |
|---|
Turning Radius (m)
| Without Brakes | 6.2 |
|---|
Tyre
| Front | 380/85R24 |
|---|---|
| Rear | 460/85R34 |
Dimention & Weight (+/- 5%)
| Gross Weight(kg) | 4085 |
|---|---|
| Wheel Base (mm) | 2376 |
| Total Length (mm) | 4311 |
| Total Width (mm) | 2255 |
| Height (mm) Up to ROPS | 2690 |
| Min Ground Clearance (mm) | 455 |
| Front Track (mm) (Standard) | 1762 |
| Rear Track (mm) (Standard) | 1724 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Registration Plate with Light | Standard |
| Front Tow Hook | Standard |
| Front & Rear Weights | 72Kg base weight+ 31×8+ Rear 40X1 (Each Wheel) |
| Drawbar | Standard |
| ROPS | Standard |
| Canopy | Optional |
| Cabin | Optional |
Optional Features
| Front Mudguard | Standard |
|---|---|
| Trailer Brake | HTB |
| Additional Weight Optional |
Front – 2X31 kg Rear – 40×1 Each Wheel | 40×2 Each Wheel
|
