Features
Engine
Power Packed Engine
Less chances of outbreak in tough condiitions
Reliable Mechanical Tractor
aerodynamic bonnet
Streamlined power with an aerodynamic bonnet!
Agri,ind&truf tyre options
Suitable for any teraain i.e Grass application, Paddy application, Industrial application
Reinforced Safety Features
Better comfort & safety during tough jobs
Technical Specifications
Engine
| Engine Type | Mitsubishi 3 Cylinder Engine |
|---|---|
| HP Category | 26 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 1318 |
| Rated RPM | 2700 |
| Air cleaner | Dry type with clogging Sensor |
| Cold Start | Standard |
| Max Torque (nm) | 76.3 |
| Exhaust | Downdraft |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Single Clutch |
| Gearbox | 6F+2R |
| Front Axle | 4WD |
| Transmission | Sliding Mesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 15.58 @ 2700 |
|---|---|
| Minimum Speed (Km/Hr) | 1.67 @ 2700 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| PTO | 540, 1000 |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 65Ah |
|---|---|
| Type of Actuation | 12V, 42Amp |
| Seven pin trailer socket  | Output 12V |
Hydraulics
| 3 Point Linkage | Cat-I |
|---|---|
| Stay Bars | Anchor Chain |
| Lifting Capacity | 600Kg |
| Auxiliary Hydraulic Circuit | 1DA |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 26 |
|---|
Turning Radius
| Without Brakes (m) | 3.1 |
|---|
Tyre
| Front | 6.00-12 |
|---|---|
| Rear | 8.30-20 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 1020 |
|---|---|
| Wheel Base (mm) | 1560 |
| Total Length (mm) | 2760 |
| Total Width (mm) | 1075 |
| Height (mm) Up to ROPS | 1955 |
| Min Ground Clearance (mm) | 240 |
| Front Track (mm) | 885 |
| Rear Track (mm) | 835 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Standard |
| Front & Rear Weights with Std. Ballast | Front weights-15×2 |
| Trailer Hitch | 1. Clevis Hitch 2. Swinging Drawbar (Optional) |
| ROPS | Standard |
Optional Features
| Tyres | TURF TYRES: Front Tyre – 23×8.50-12 Rear Tyre – 33×15.50-16.5 INDUSTRIAL TYRES: Front Tyre- 23×8.50-12 Rear Tyre- 33×15.50-16.5 |
|---|
