Features
Engine
Agile High Backup Torque Engine
Lifting Capacity
Heavy Duty 1600 Kg Lifting Capacity
8F+2R Swift Shift Transmission
Jerk Free & Noise free Gear Shifting
heavy Duty 2wd/4wd
Powerful 2WD/4WD tractors for tough tasks.
easy front and loader attachment
Effortless front loader attachment for tractors.
Technical Specifications
Engine
Engine Type | Three Cylinder Natural Aspirated Engine |
---|---|
HP Category | 50 |
No. of Cylinders | 3 |
Aspiration | Natural |
Cubic Capacity (cc) | 3067 |
Rated RPM | 2100 |
Air cleaner | Dry Air Cleaner with Clogging sensor |
Cold Start | Yes, Optional |
Max Torque (nm) (+/-5%) | 205(± 5%) @ 1200 ± 100 |
Exhaust | Updraft Silencer |
Transmission
Drive | 4WD |
---|---|
Clutch | Dual Clutch |
Gearbox | 8F+2R |
Front Axle | Dana Axle |
Transmission | Constant Mesh |
Speed (Forward)
Maximum Speed (Km/Hr) | 32.44 |
---|---|
Minimum Speed (Km/Hr) | 2.46 |
Brakes
Brakes | Oil Immersed Brakes |
---|---|
Type of actuation | Mechanical |
Hand Brake | Yes |
Differential Lock
Differential Lock | Yes, Foot Operated |
---|
PTO
PTO (RPM) | 540 |
---|---|
PTO (Actuation) | Mechanical |
Steering
Steering | Power Steering |
---|
Electrical
Battery | 12V, 88 Ah |
---|---|
Alternator | 12V, 36 Amp |
Seven Pin Trailer Socket | Yes |
Hydraulics
3 Point Linkage | CAT-II |
---|---|
Stay Bars | Adjustable |
Hydraulic Lifting Capacity | 1600 kg |
Auxiliary Hydraulic Circuit | 1DA |
Safety Switch
Clutch Safety Switch | Standard |
---|
Capacity (Ltrs) (+/- 5%)
Fuel Tank (Lit) | 55 |
---|
Turning Radius
Without Brakes (m) | 6.9 |
---|
Tyre
Front | 8-18 |
---|---|
Rear | 14.9-28 |
Dimention & Weight (+/- 5%)
Weight (Kg) | 2019 (Unbalast weight) |
---|---|
Wheel Base (mm) | 2108 |
Total Length (mm) | 3876 |
Total Width (mm) | 1800 |
Height (mm) (Up to Exhaust Pipe) | 2281 |
Min Ground Clearance (mm) min | 382 |
Others
Fuel Indicator Gauge | Yes |
---|---|
Front Tow Hook | Inbuilt in Front Weight |
Front & Rear Weights with Std. Ballast | Base Weight 72Kg + Front Weight 6X31Kg
Rare1X34 Kg on each wheel |
Trailer Hitch | Auto trailer Hitch |
