Features
Engine
Agile High Backup Torque Engine
8F+2R Transmission
Jerk Free & Noise free Gear Shifting
Lifting Capacity
Heavy Duty Lifting Capacity
Easy Front and Loader attachment
Parallelogram Loader Option
heavy Duty 2wd/4wd
Powerful, versatile tractor for tough tasks
Technical Specifications
Engine
| Engine Type | 4100 FLT |
|---|---|
| HP Category | 75 |
| No. of Cylinders | 4 |
| Aspiration | Turbo Charged |
| Cubic Capacity (cc) | 3707 |
| Rated RPM (+/-mm) | 2200 |
| Air cleaner | Dry Type |
| Cold Start | Standard |
| Max Torque (nm) (+/- 5%) | 278 @ 1200 |
| Exhaust | Updraft (Elliptical) |
Transmission
| Drive | 4WD/2WD |
|---|---|
| Clutch | Dual, Dry Friction Plate |
| Gearbox | 8F+2R |
| Front Axle | 4WD |
| Transmission | Constant Mesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 35.75 |
|---|---|
| Minimum Speed (Km/Hr) | 3.03 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of Actuation | Mechanical |
| Parking Brake | Independent Type |
Differential Lock
| Differential Lock | Standard |
|---|
PTO
| PTO (RPM) | 540 @ 1680 Erpm |
|---|
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 110 AH |
|---|---|
| Alternator | 12V, 36 Amp |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| 3 Point Linkage | CAT – II |
|---|---|
| Stay Bars | Swinging Drawbar |
| Hydraulic Lifting Capacity (Kg) | 2000 |
| Auxiliary Hydraulic Circuit | 1SA/1DA |
| Lift Rods | Standard |
Safety Switch
| Neutral Safety Switch | Standard |
|---|
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 65 |
|---|
Tyre
| Front | 7.5-16 |
|---|---|
| Rear | 16.9-30 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 2610 |
|---|---|
| Wheel Base (mm) | 2210 |
| Total Length (mm) | 3740 |
| Total Width (mm) | 1910-2250 |
| Height (mm) Up to ROPS | 1770 (Steering), 2400 with Exhaust |
| Min Ground Clearance (mm) | 385 |
| Front Track (mm) | 1360-1710 |
| Rear Track (mm) | 1455-1785 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Standard, Inbuilt in Front Weight |
| Front & Rare Weights With Std. Ballast |
Front – 72 kg Base Wt+6X31,  Rare – 1X34 on each wheel |
| Trailer Hitch | Swinging Drawbar |
