Features
Mitsubishi 3‑cylinder engine
Reliable power for heavy work
Twin projector headlamps
Improved visibility for night operations
4WD heavy‑duty front axle
Better traction in tough fields
6F+2R mechanical transmission
Precise speed control for implements
1DA auxiliary hydraulic circuit
Easy attachment operation on demand
Technical Specifications
ENGINE
| Engine Type | Mitsubishi 3 Cylinder |
| HP Category | 30 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 1318 |
| Rated RPM | 3000 |
| Air Cleaner | Dry Type with Clogging Sensor |
| Cold Start | Standard |
| Max Torque (nm) | 82 Nm |
| Exhaust | Downdraft Exhaust |
TRANSMISSION
| Drive | 4WD |
| Clutch | Sliding Mesh |
| Gearbox | 6F + 2R |
| Front Axle | 4WD (Heavy Duty) |
| Transmission | Sliding Mesh |
SPEED (FORWARD)
| Maximum Speed (Km/Hr) | 17.06 Kmph |
| Minimum Speed (Km/Hr) | 1.82 Kmph |
BRAKES
| Brakes | Oil Immersed Brakes |
| Type of Actuation | Mechanical |
| Parking Brake | Latch Type |
DIFFERENTIAL LOCK
| Differential Lock | Mechanical, Foot Operated |
PTO
| PTO (rpm) | 540/1000 RPM |
| PTO (Actuation) | Mechanical |
STEERING
| Steering | Power |
ELECTRICALS
| Battery | 12V, 65 Ah |
HYDRAULICS
| 3 Point Linkage | Cat 1-N |
| Stay Bars | Anchor Chain |
| Lifting Capacity | 600 Kg |
| Auxiliary Hydraulic Circuit | 1DA |
| Flow(LPM) | 18 |
SAFETY SWITCH
| Clutch Safety Switch | Standard |
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
CAPACITY (LTRS) (+/- 5%)
| Fuel Tank | 26 L |
TURNING RADIUS
| Without Brakes (m) | 3.2 |
TYRE
| Front | 7.00 x 14 |
| Rear | 8.30 x 24 |
DIMENSIONS & WEIGHT
| Weight (Kg) | 1030 |
| Wheel Base (mm) | 1570 |
| Wheel Base (mm) | 1570 |
| Total Length (mm) | 2760 |
| Total Width (mm) | 1165 |
| Height (mm) Up to ROPS | 2000 |
| Min Ground Clearance (mm) | 265 |
| Front Track (mm) | 950 |
| Rear Track (mm) | 815 |
OTHERS
| Fuel Indicator Gauge | Standard |
| Front Tow Hook | Standard |
| Front & Rear Weights with Std. Ballast | Front Weights 15 x 2 |
| Trailer Hitch | E‑Marked Swinging Bar; Clevis Hitch (Optional); Semi Automatic Hitch |
| Height (mm) Up to ROPS | 2000 |
| ROPS | Standard |
| Canopy | Standard |
OPTIONAL FEATURES
| Tyres |
TURF Front Tyre: 23×8.50-12 Rear Tyre: 33×15.50-16.5 INDUSTRIAL AGRI RADIAL GALAXY PRO |
