Features

Engine

In house Power Packed Engine

Less chances of outbreak in tough condiitions

Reliable Mechanical Tractor

Headlamp

Twin Projector Headlamps, better visibility in night

Multiple Tyre Options

Suitable for any teraain i.e Grass application, Paddy application, Industrial application

Reinforced Safety Features

Better comfort & safety during tough jobs

Technical Specifications

Engine

Engine Type Mitsubishi 3 Cylinder Engine
HP Category 26
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 1318
Rated RPM 2700
Air cleaner Dry
Cold Start Standard
Max Torque (nm) 76.3 @ 2700
Exhaust Underhood Downdraft Silencer

Transmission

Drive 4WD
Clutch Single Clutch
Gearbox 6F+2R
Front Axle 4WD
Transmission Sliding Mesh

Speed (Forward)

Maximum Speed (Km/Hr) 14.04 @ 2700
Minimum Speed (Km/Hr) 1.50 @ 2700

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical
Parking Brake Independent

Differential Lock

Differential Lock Yes, Foot Operated

PTO

PTO 540, 1000
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 65Ah
Type of Actuation 12V, 42Amp
Parking Brake Standard

Hydraulics

3 Point Linkage Cat-I
Stay Bars Anchor Chain
Lifting Capacity 600Kg
Auxiliary Hydraulic Circuit 1DA/ 1SA (Optional)
Lift Rods Standard
Flow(LPM) 18

Safety Switch

Clutch Safety Switch Standard
PTO Safety Switch Standard
Neutral Safety Switch Standard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 26.5

Turning Radius

Without Brakes (m) 2.3

Tyre

Front 6.00-12
Rear 8.30-20

Dimention & Weight (+/- 5%)

Weight (Kg) 960
Wheel Base (mm) 1560
Total Length (mm) 2725
Total Width (mm) 1058
Height (mm) Up to ROPS 2153
Min Ground Clearance (mm) 255
Front Track (mm) 894
Rear Track (mm) 825

Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard
Front & Rear Weights with Std. Ballast Front weights-15×2
Trailer Hitch 1. Clevis Hitch
2. Swinging Drawbar (Optional)
Height (mm) Up to ROPS 2153
ROPS Standard

Optional Features

Tyres TURF TYRES:
Front Tyre – 23×8.50-12
Rear Tyre – 33×15.50-16.5
INDUSTRIAL TYRES:
Front Tyre- 23×8.50-12
Rear Tyre- 33×15.50-16.5

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Rotary Slasher
