Features

Engine

Agile 4 Cylinder Engine

Constant Mesh 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Swift and easy loader operations

Parallelogram Loader Option

For comfortable operations under tough weather conditions

Integrated Safety HVAC Cabin (Optional)

Technical Specifications

Engine

Engine Type 4100FLT
HP Category 75
No. of Cylinders 4
Aspiration Turbo Charged
Cubic Capacity (cc) 3707
Rated RPM (+/-mm) 2200
Air cleaner Dry Type with Clogging Sensor
Cold Start Standard
Max Torque (nm) (+/- 5%) 278 @ 1300ERPM
Exhaust Elliptical Upward

Transmission

Drive 4WD
Clutch Dual Clutch
Gearbox 8F+2R
Transmission Swift Shift

Speed (Forward)

Maximum Speed (Km/Hr) 36.46 @ 2200
Minimum Speed (Km/Hr) 1.95 @ 2200

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical
Parking Brake Independent

Differential Lock

Differential Lock Standard, Foot Operated

PTO

PTO (RPM) 540
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 110/88 Ah
Alternator 12V, 36Amps
Seven Pin Trailer Socket Standard

Hydraulics

3 Point Linkage CAT-II
Stay Bars Adjustable
Hydraulic Lifting Capacity 2500Kg
Auxiliary Hydraulic Circuit 1DA+1SA
Lift Rods Standard

Safety Switch

Neutral Safety Switch Standard
Clutch Safety Switch Standard
Neutral Safety Switch Standard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 65

Tyre

Front 11.2-24
Rear 16.9-30

Dimention & Weight (+/- 5%)

Unballast Weight 2742
Wheel Base (mm) 2307
Total Length (mm) 3997
Total Width (mm) 1942
Height (mm) Up to ROPS 2620
Min Ground Clearance (mm) 293
Front Track (mm) (Standard) 1672
Rear Track (mm) (Standard) 1515

Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard, Inbuilt in Front Weight
Front & Rear Weights with Std. Ballast Front- 2X30Kg, 4X25, Rear- 1X34 Kg
Trailer Hitch Swinging Drawbar
ROPS Standard

Optional Features

Canopy Optional
2WD Variant Standard
Tyre 2WD Front: 7.5X16

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
