Features

Engine

In house Powerful 110 HP 4 Cylinder Engine

Lifting Capacity

Heavy Duty 4500 Kg Lifting Capacity

Option Available

Available in Cabin/ ROPS

Circuit

3SA/ 3DA Auxiliary Hydraulic Circuit

Technical Specifications

Engine

Engine Type 110 HP Powerful 4 Cylinder Engine
HP Category 110
No. of Cylinders 4
Displacement (ltr) 4127
Aspiration Turbo charged with CAC (TCIC)
Bore/Stroke (mm) 105/118
Air cleaner Three stage Dry Air Type

Transmission

Drive 4WD
Clutch Double Clutch
Gearbox 24F + 24R
Transmission Synchromesh

Speed (Forward)

Maximum Speed (Km/Hr) 36.58 @ 2200 RPM
Minimum Speed (Km/Hr) 0.5 @ 2200 RPM
Driver Seat Mechanical Suspension

Brakes

Brakes Oil Immersed Brakes
Type of actuation Hydraulically Assisted
Parking Brake Independent
Trailer Brake HTB

Differential Lock

Differential Lock Standard (Electrical Switch Operated)

PTO

PTO (RPM) 540/540E
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 110Ah
Alternator 12V, 90Amp
Seven Pin Trailer Socket Standard

Hydraulics

Position Control Standard
Automatic Draft Control Standard
3 Point Linkage Cat-II
Lifting Capacity 4500Kg
Auxiliary Hydraulic Circuit 2DA / 2SA + 1DA (Detent & Float type)

Safety Switch

Neutral Safety Switch Standard
P.T.O Safety Switch Standard
Clutch Safety Switch Standard

Capacity (Ltrs) (+/- 5%) Approx

Fuel Tank (Lit) 117
Eng Oil (Ltr) 11.75

Tyre

Front 380/85R24
Rear 460/85R34

Dimention & Weight (+/- 5%)

Gross Weight(kg) 4250 (With Std. Ballast)
Wheel Base (mm) 2376
Total Length (mm) 4045
Total Width (mm) 2225
Height (mm) Up to ROPS 2968
Min Ground Clearance (mm) 488
Front Track (mm) (Standard) 1762
Rear Track (mm) (Standard) 1724

Others

Fuel Indicator Gauge Standard
Registration Plate with Light Standard
Front Tow Hook Standard
Front & Rear Weights Front 31×10+72Kg base weight Rear 2×40 Kg
Drawbar Standard
ROPS Standard
Canopy Standard

Optional Features

Canopy Standard
Tyres Front: 12.4 – 28 (TR – 171)
Rear: 16.9 – 38 (TR – 171)

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
