Features
3 CYLINDER MITSUBISHI ENGINE
Reliable power for demanding field work
TWIN PROJECTOR LAMPS
Clearer visibility for safer night operations
HEAVY DUTY 4WD FRONT AXLE
Strong grip for tough terrain
MECHANICAL TRANSMISSION
Delivers speed and precision across operations
AERO DYNAMICS BONNET
Sleek design improves airflow and cooling
Technical Specifications
ENGINE
| Engine Type | Mitsubishi 3 Cylinder |
| HP Category | 30 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 1318 |
| Rated RPM | 3000 |
| Air Cleaner | Dry Type with Clogging Sensor |
| Cold Start | Standard |
| Max Torque (nm) | 82 Nm |
| Exhaust | Downdraft Exhaust |
TRANSMISSION
| Drive | 4WD |
| Clutch | Sliding Mesh |
| Gearbox | 6F + 2R |
| Front Axle | 4WD (Heavy Duty) |
| Transmission | Sliding Mesh |
SPEED (FORWARD)
| Maximum Speed (Km/Hr) | 17.06 Kmph |
| Minimum Speed (Km/Hr) | 1.82 Kmph |
BRAKES
| Brakes | Oil Immersed Brakes |
| Type of Actuation | Mechanical |
| Parking Brake | Latch Type |
DIFFERENTIAL LOCK
| Differential Lock | Mechanical, Foot Operated |
PTO
| PTO (rpm) | 540/1000 RPM |
| PTO (Actuation) | Mechanical |
STEERING
| Steering | Power |
ELECTRICALS
| Battery | 12V, 65 Ah |
HYDRAULICS
| 3 Point Linkage | Cat 1-N |
| Stay Bars | Anchor Chain |
| Lifting Capacity | 600 Kg |
| Auxiliary Hydraulic Circuit | 1DA |
| Flow(LPM) | 18 |
SAFETY SWITCH
| Clutch Safety Switch | Standard |
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
CAPACITY (LTRS) (+/- 5%)
| Fuel Tank | 26 L |
TURNING RADIUS
| Without Brakes (m) | 3.2 |
TYRE
| Front | 7.00 x 14 |
| Rear | 8.30 x 24 |
DIMENSIONS & WEIGHT
| Weight (Kg) | 1030 |
| Wheel Base (mm) | 1570 |
| Total Length (mm) | 2760 |
| Total Width (mm) | 1165 |
| Height (mm) Up to ROPS | 2000 |
| Min Ground Clearance (mm) | 265 |
| Front Track (mm) | 950 |
| Rear Track (mm) | 815 |
OTHERS
| Fuel Indicator Gauge | Standard |
| Front Tow Hook | Standard |
| Front & Rear Weights with Std. Ballast | Front Weights 15 x 2 |
| Trailer Hitch | E-Marked Swinging Bar; 2. Clevis Hitch (Optional); 3. Semi-Automatic Hitch |
| Height (mm) Up to ROPS | 2000 |
| ROPS | Standar |
OPTIONAL FEATURES
| Tyres |
TURF Front Tyre: 23×8.50-12 Rear Tyre: 33×15.50-16.5 INDUSTRIAL AGRI RADIAL GALAXY PRO |
