Features

Engine

In house powerful 3 Cylinder Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R Swift Shift Transmission

Jerk Free & Noise free Gear Shifting

Multiple tyre option

Radial & Bias Tyre suitable for durability and maneuverability

Reinforced Safety Features

Better comfort & safety during tough jobs

Technical Specifications

Engine

Engine Type Three Cylinder Natural Aspirated Engine
HP Category 50
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 3067
Rated RPM 2100
Air cleaner Dry Air Cleaner with Clogging sensor
Cold Start Standard
Max Torque (nm) (+/-5%) 205 @ 1200 ± 100RPM
Exhaust Underhood Downdraft Silencer Underhood Upward

Transmission

Drive 2WD/4WD
Clutch Dual Clutch
Gearbox 8F+2R
Front Axle 4WD
Transmission Swift Shift

Speed (Forward)

Maximum Speed (Km/Hr) 29.94@2100
Minimum Speed (Km/Hr) 2.27@2100

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical
Parking Brake Independent

Differential Lock

Differential Lock Yes, Foot Operated

PTO

PTO (RPM) 540
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 88 Ah
Alternator 12V, 90 Amp
Seven Pin Trailer Socket Standard

Hydraulics

3 Point Linkage CAT-II
Stay Bars Adjustable
Hydraulic Lifting Capacity 1600 kg
Auxiliary Hydraulic Circuit 2DA
Lift Rods Standard

Safety Switch

Neutral Safety Switch Standard
Clutch Safety Switch Standard
Neutral Safety Switch Standard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 65

Turning Radius

Without Brakes (m) 3.7

Tyre

Front 9.5-20
Rear 13.6-28

Dimention & Weight (+/- 5%)

Weight (Kg) 2780
Wheel Base (mm) 2175
Total Length (mm) 3936
Total Width (mm) 1785
Height (mm) Up to ROPS 2488
Min Ground Clearance (mm) 293
Front Track (mm) 1535
Rear Track (mm) 1420

Others

Fuel Indicator Gauge Standard
Front Tow Hook Inbuilt in Front Weight
Front & Rear Weights with Std. Ballast 30X2+25X4
Trailer Hitch Swinging Drawbar
ROPS Standard

Optional Features

Tyres (Radial Tyre) Front 250/85R20, Rear 340/85R28
Cabin Optional
2WD Front Tyre 7.5-16

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
