Features
Engine
In house Powerful 3 Cylinder Engine
Swift Shift 8F+2R Transmission
Jerk Free & Noise free Gear Shifting
Lifting Capacity
Heavy Duty Lifting Capacity
Swift and easy loader operations
Parallelogram Loader Option
For comfortable operations under tough weather conditions
Integrated Safety HVAC Cabin (Optional)
Technical Specifications
Engine
| Engine Type | 3100 FLT |
|---|---|
| HP Category | 60 |
| No. of Cylinders | 3 |
| Aspiration | Turbo |
| Cubic Capacity (cc) | 2780 |
| Rated RPM | 2100 |
| Air cleaner | Dry Type |
| Cold Start | Standard |
| Max Torque (nm) | 230Nm @ 1300ERPM |
| Exhaust | Underhood / Upward |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Dual Clutch |
| Gearbox | 8F+2R |
| Front Axle | 4WD |
| Transmission | Swift Shift |
Speed (Forward)
| Maximum Speed (Km/Hr) | 33.67 |
|---|---|
| Minimum Speed (Km/Hr) | 2.52 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Standard |
|---|
PTO
| PTO (RPM) | 540 |
|---|
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 88 Ah |
|---|---|
| Alternator | 12V, 36Amp |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| 3 Point Linkage | CAT-II |
|---|---|
| Stay Bars | Swinging Drawbar |
| Hydraulic Lifting Capacity | 2000 kg |
| Auxiliary Hydraulic Circuit | 2DA |
| Lift Rods | Standard |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 62 |
|---|
Tyre
| Front | 9.5-24 |
|---|---|
| Rear | 16.9*28 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 2500 |
|---|---|
| Wheel Base (mm) | 2350 |
| Total Length (mm) | 3980 |
| Total Width (mm) | 1790-1950 |
| Height (mm) Up to ROPS | 2650 |
| Min Ground Clearance (mm) | 360 |
| Front Track (mm) | 1295-1650 |
| Rear Track (mm) | 1420-1880 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Inbuilt in Front Weight |
| Front & Rear Weights with Std. Ballast | Base Weight 72 Kg + Front Weight 6X31 Kg |
| Trailer Hitch | Swinging Drawbar |
| ROPS | Standard |
Optional Features
| Tyre | 9.5/20 & 16.9*28 |
|---|
