Technical Specifications

Engine

Engine Type Mitsubishi 3 Cylinder
HP Category 20
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 952
Rated RPM 2700
Air cleaner Dry
Cold Start Yes
Max Torque (nm) 50
Exhaust Underhood Downdraft Silencer

Transmission

Drive 4WD
Clutch Single Clutch
Gearbox 6F+2R
Front Axle 4WD
Transmission Sliding Mesh

Speed (Forward)

Maximum Speed (Km/Hr) 15.26@2700
Minimum Speed (Km/Hr) 1.3@2700

Brakes

Brakes Dry Drum Brakes
Type of actuation Mechanical
Parking Brake Independent

Differential Lock

Differential Lock Yes, Foot Operated

PTO

PTO (RPM) 540, 540E, 1000*
PTO (Actuation) Mechanical

Steering

Steering Power Steering

Electrical

Battery 12V, 65Ah
Alternator 12V, 42Amp
Parking Brake Yes

Hydraulics

3 Point Linkage CAT-I
Stay Bars Anchor Chain
Auxiliary hydraulic circuit 1DA/1SA (optional)
Lift rods Yes
Lifting capacity 500kg
Litre Per Minute (LPM) 12

Safety Switch

Clutch Safety Switch Yes
PTO Safety Switch Yes
Neutral Safety Switch Yes

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 26.5

Turning Radius

Without Brakes (m) 2.3

Tyre

Front 5.00 – 12
Rear 8.00 – 18

Dimention & Weight (+/- 5%)

Weight (Kg) (Unballast) 885
Wheel Base (mm) 1420
Total Length (mm) 2710
Total Width (mm) 925
Height (mm) Up to ROPS 1925
Min Ground Clearance (mm) 220
Front Track (mm) 820
Rear Track (mm) 725

Others

Fuel Indicator Gauge Yes
Front Tow Hook Yes
Front & rear weights with std. Ballast Front weight – 2X15 Kg
Trailer Hitch 1. Clevis Hitch
2. Swinging Drawbar (Optional)
ROPS Yes

Optional Features

Tyres TURF TYRES:
Front Tyre – 23×8.50-12
Rear tyre – 33×15.50 – 16.5
INDUSTRIAL TYRES:
Front tyre- 23×8.50-12
Rear tyre- 33×15.50-16.5
