Features
Engine
In house Powerful 110 HP 4 Cylinder Engine
Lifting Capacity
Heavy Duty 4500 Kg Lifting Capacity
Option Available
Available in Cabin/ ROPS
Circuit
2DA, 2SA + 1DA Auxiliary Hydraulic Circuit
Constant Mesh 24F+24R Transmission
Jerk Free & Noise free Gear Shifting
Technical Specifications
Engine
| Engine Type | SONALIKA 110 |
|---|---|
| HP Category | 110 HP |
| No. of Cylinders | 4 |
| Displacement (ltr) | 4087 |
| Aspiration | Turbo charged with CAC (TCIC) |
| Bore/Stroke (mm) | 105/118 |
| Rated RPM | 2200 |
| Air cleaner | Three stage Dry Air Type |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Double Clutch |
| Gearbox | 24F + 24R |
| Transmission | Synchromesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 37 @ 2200 RPM |
|---|---|
| Minimum Speed (Km/Hr) | 0.5 @ 2200 RPM |
| Driver Seat | Mechanical Suspension |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Hydraulically Assisted |
| Parking Brake | Independent |
| Trailer Brake | HTB |
Differential Lock
| Differential Lock | Standard (Electrical Switch Operated) |
|---|
PTO
| PTO (RPM) | 540/540E |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 110Ah |
|---|---|
| Alternator | 12V, 90Amp |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| Position Control | Standard |
|---|---|
| Automatic Draft Control | Standard |
| 3 Point Linkage | Cat-II |
| Lifting Capacity | 4500Kg |
| Auxiliary Hydraulic Circuit | 2DA, 2SA + 1DA (with Float & Detent) |
Safety Switch
| Neutral Safety Switch | Standard |
|---|---|
| P.T.O Safety Switch | Standard |
| Clutch Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%) Approx
| Fuel Tank (Lit) | 115 |
|---|---|
| Eng Oil (Ltr) | 11.75 |
TURNING RADIUS IN (M)
| Without Brakes & with Brake | 5.7 |
|---|
Tyre
| Front | 380/85R24 |
|---|---|
| Rear | 460/85R34 |
Dimention & Weight (+/- 5%)
| Gross Weight(kg) | 4250 |
|---|---|
| Wheel Base (mm) | 2376 |
| Total Length (mm) | 4045 |
| Total Width (mm) | 2225 |
| Height (mm) Up to ROPS | 2816 |
| Ground Clearance (mm) min | 488 |
| Front Track, (mm), Std. | 1762 |
| Rear Track, (mm), Std. | 1724 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Registration Plate with Light | Standard |
| Front Tow Hook | Standard |
| Front & Rear Weights | Front 31×10+72Kg base weight Rear 40×2 Kg |
| Drawbar | Standard |
| ROPS | Standard |
| Canopy | Standard |
Optional Features
| Cabin | Yes |
|---|---|
| Front Mudgard | Yes |
