Features

Engine

Three Cylinder Natural Aspirated Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R Swift Shift Transmission

Jerk Free & Noise free Gear Shifting

Reinforced Safety Features

Metalic Body, Better comfort & safety during tough jobs

Variants

Heavy Duty 2WD

Technical Specifications

Engine

Engine TypeThree Cylinder Natural Aspirated Engine
HP Category50
No. of Cylinders3
AspirationNatural
Cold StartNo
Cubic Capacity (cc)2893
Rated RPM2100
Air cleanerDry Air Cleaner with Clogging sensor
Cold StartStandard
Max Torque (nm) @ RPM190 (±5%) @ 1200 ± 100
ExhaustUpdraft

Transmission

Drive2WD
ClutchSingle
Gearbox8F+2R
Front AxleFixed Type
TransmissionConstant Mesh

Speed (Forward)

Maximum Speed (Km/Hr)3.04
Minimum Speed (Km/Hr)30.68

Brakes

BrakesOil Immersed Brakes
Type of actuationMechanical
Hand BrakeYes

Differential Lock

Differential LockYes, Foot Operated

PTO

PTO (RPM)540
PTO (Actuation)Mechanical

Steering

SteeringPower Steering

Electrical

Battery12V, 88 Ah
Alternator36 AMP, 12V
Seven Pin Trailer SocketYes

Hydraulics

3 Point LinkageCAT-II
Lifting Capacity1600 kg
Auxiliary Hydraulic Circuit 1SA

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)55

TURNING CIRCLE IN (M)

Without Brakes (m)7.41

Tyre

Front 6-16
Rear13.6-28

Dimention & Weight (+/- 5%)

Gross Weight(kg)1837 (Unballast Weight)
Wheel Base (mm)2074
Total Length (mm)3880
Total Width (mm)1776
Height (mm) (upto Exhaust Pipe)2277
Ground Clearance (mm) min392

Others

Fuel Indicator GaugeYes
Front Tow HookYes, inbuilt in front weight
Front & Rear Weights with Std. BallastBase Weight 72 Kg + 4*31 Kg
Trailer HitchAuto Trailer Hitch

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
