Features

Engine

Three Cylinder Natural Aspirated Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R constant Mesh Transmission

Jerk Free & Noise free Gear Shifting

Reinforced Safety Features

Metalic Body, Better comfort & safety during tough jobs

Variants

Heavy Duty 4WD

Technical Specifications

Engine

Engine Type Three Cylinder Natural Aspirated Engine
HP Category 50
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 3067
Rated RPM 2100
Air cleaner Dry air cleaner with clogging sensor
Cold Start Standard
Max Torque (nm) (+/-5%) 205 (±5%) @ 1200 ± 100
Exhaust Updraft

Transmission

Drive 4WD
Clutch Dual Clutch
Gearbox 8F+2R
Front Axle Dana Axle
Transmission Constant Mesh

Speed (Forward)

Min Speed(km/h) 2.46
Max Speed(km/h) 32.44

Brakes

Brakes Oil Immersed Brake
Type of actuation Mechanical
Hand Brake Yes



Differential Lock

Differential Lock Yes, Foot Operated

PTO

Power Take Off (RPM) 540
Power Take Off (Actuation) Mechanical

Steering

Steering Power Steering

Electrical

Battery 12V, 88 Ah
Alternator 36 AMP, 12V
Seven Pin Trailer Socket Yes

Hydraulics

3 Point Linkage CAT-II
Lifting Capacity 1600Kg
Auxiliary Hydraulic Circuit 1DA

Safety Switch

Clutch Safety Switch Yes

Capacity (Ltrs) (+/- 5%)

Fuel Tank 55

TURNING CIRCLE IN (M)

Without Brakes 6.9

Tyre

Front  8-18
Rear 14.9-28

Dimention & Weight (+/- 5%)

Gross Weight(kg) 2019 (Unballast Weight)
Wheel Base (mm) 2108
Total Length (mm) 3876
Total Width (mm) 1800
Height (mm) (upto Exhaust Pipe) 2281
Ground Clearance (mm) min 382

Others

Fuel Indicator Gauge Yes
Front Tow Hook Yes, inbuilt in front weight
Front & rear weights with std. Ballast Base Weight 72Kg+Front 6X31 Kg
Rear 1X34 Kg on each wheel
Trailer Hitch Auto Trailer Hitch

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
