Features
Engine
Powerful 90 HP 4 Cylinder Engine
Lifting Capacity
Heavy Duty 3000 Kg Lifting Capacity
Reinforced Safety Features
Metalic Body, Better comfort & safety during tough jobs
Variants
Heavy Duty 2WD/4WD
Synchromesh 12F+12R Transmission
Jerk Free & Noise free Gear Shifting
Technical Specifications
Engine
| Engine Type | 4 Cylinder Turbo Charged Engine |
|---|---|
| HP Category | 90 |
| No. of Cylinders | 4 |
| Aspiration | Turbo Charged |
| Cubic Capacity (cc) | 4087 |
| Rated RPM (+/-mm) | 2200 |
| Air cleaner | Dry Air Cleaner with Clogging Sensor |
| Cold Start | Standard |
| Max Torque (nm) (+/- 5%) | 276.79 @ 2200 |
| Exhaust | Underhood Downdraft Silencer Underhood Upward |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Double Clutch |
| Gearbox | 12F+12R |
| Transmission | Synchronmesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 35.2@2200 |
|---|---|
| Minimum Speed (Km/Hr) | 0.57@2200 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Mechanical, Foot Operated |
|---|
PTO
| PTO (RPM) | 540/540E |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V 110 AH |
|---|---|
| Alternator | 12V, 36Amps |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| 3 Point Linkage | CAT-II |
|---|---|
| Stay Bars | Adjustable |
| Hydraulic Lifting Capacity | 2500Kg (3000 Kg Optional) |
| Auxiliary Hydraulic Circuit | 2DA/2SA |
| Lift Rods | Standard |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 78 |
|---|
Turning Radius
| Without Brakes (m) | LHS-6.13, RHS-6.18 |
|---|
Tyre
| Front | 12.4*24 |
|---|---|
| Rear | 18.4*30 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 3255 |
|---|---|
| Wheel Base (mm) | 2350 |
| Total Length (mm) | 3980 |
| Total Width (mm) | 2400 |
| Height (mm) Up to ROPS | 2640 |
| Min. Ground Clearance (mm) | 3405 |
| Front Track (mm) (Standard) | 1495-1835 |
| Rear Track (mm) (Standard) | 1500-1900 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Standard, Inbuilt in Front Weight |
| Front & Rear Weights with Std. Ballast | Front:- 10*31Kg Rear:- 1*34 Kg on each wheel |
| Trailer Hitch | Swinging Drawbar |
| ROPS | Standard |
