Features
Engine
Agile 4 Cylinder Engine
Constant Mesh 8F+2R Transmission
Jerk Free & Noise free Gear Shifting
Lifting Capacity
Heavy Duty 2000Kg Lifting Capacity
Circuit
1SA/1DA Auxiliary Hydraulic Circuit
Option Available
Available in Canopy/ ROPS
Technical Specifications
Engine
| Engine Type | 4100FLT |
|---|---|
| HP Category | 75 |
| No. of Cylinders | 4 |
| Aspiration | Turbo Charged |
| Bore/Stroke(mm) | 100/118 |
| Cubic Capacity (cc) | 3707 |
| Rated RPM (+/-25mm) | 2200 |
| Air Cleaner | Dry Type |
| Max Torque (Nm) @ RPM | 246.43 @ 1201 |
| Exhaust | Updraft (Elliptical) |
Transmission
| Drive | 2WD |
|---|---|
| Clutch | Dual, Dry Friction Plate |
| Gearbox | 8F+2R |
| Transmission | Constant Mesh |
Speed (Forward)
| Min Speed(km/h) | 3.03 |
|---|---|
| Max Speed(km/h) | 35.75 |
| Driver Seat | Adjustable |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical (Ind) |
| Hand Brake | Yes |
Differential Lock
| Differential Lock (mechanical) | Yes |
|---|
Power Take Off
| Power Take off (RPM) | 540 PTO rpm @ 1680 erpm |
|---|---|
| Power Take off (Actuation) | Type 1 Independent (Mechanical) |
Steering
| Steering | Power Steering |
|---|
Electrical
| Battery | 12v Dc Electrical |
|---|---|
| Alternator | 12V, 36 AMP |
| Seven Pin Trailer Socket | Yes |
Hydraulics
| Position Control | Yes |
|---|---|
| Automatic Draft Control | Yes |
| 3 Point Linkage | CAT II |
| Lifting Capacity | 2000Kg |
| Auxiliary Hydraulic Circuit | 1SA/1DA |
| No. of Spool Valves | Floor Operated -3, Back Plate-2 |
Safety Switch
| Neutral Safety Switch | Yes |
|---|---|
| P.T.O Safety Switch | Yes |
| Clutch Safety Switch | Yes |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank | 62L |
|---|---|
| Engine Oil | 12.5L |
| Hydraulic + Transmission | 58L |
Tyre
| Option 1 | Front:- 7.5-16 Rear:- 16.9-30 |
|---|
Dimention & Weight (+/- 5%)
| Gross Weight (kg) | 2610 |
|---|---|
| Wheel Base (mm) | 2210 |
| Total Length (mm) | 3740 |
| Total Width (mm) | 1910-2250 |
| Height (mm) Up to ROPS | 1770 (Steering), 2400 With Exhaust |
| Ground Clearance (mm) min | 385 |
| Front Track, (mm), min.-max. | 1360-1710 |
| Rear Track, (mm), min.-max. | 1455-1785 |
Others
| Fuel Indicator Gauge | Yes |
|---|---|
| Registration Plate With Light | Optional |
| Front Tow Hook | Yes (Fixed) |
| Front & Rear Weights | Front-72 Kg Base Wt+6×31, Rear-1×34 On Each Wheel |
| Drawbar | Linkage & Swinging Drawbar |
| ROPS | Optional |
| Canopy | Optional |
Optional Features
| Trailer Brake | Optional |
|---|---|
| 2WD Variant | Yes |
