Features
Engine
Agile 4 Cylinder Engine
Swift Shift 8F+2R Transmission
Jerk Free & Noise free Gear Shifting
Lifting Capacity
Heavy Duty Lifting Capacity
Swift and easy loader operations
Parallelogram Loader Option
For comfortable operations under tough weather conditions
Integrated Safety HVAC Cabin (Optional)
Technical Specifications
Engine
| Engine Type | 4100 FL |
|---|---|
| HP Category | 60 |
| No. of Cylinders | 4 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 3707 |
| Rated RPM | 2200 |
| Air cleaner | Dry Type with Clogging Sensor |
| Cold Start | Standard |
| Max Torque (nm) (+/- 5%) | 230 @ 1300 ERPM |
| Exhaust | Underhood Downdraft Silencer Underhood Upward |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Dual Clutch |
| Gearbox | 8F+2R |
| Front Axle | 4WD |
| Transmission | Swift Shift |
Speed (Forward)
| Maximum Speed (Km/Hr) | 36.46 |
|---|---|
| Minimum Speed (Km/Hr) | 1.95 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent Type |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| PTO (RPM) | 540 |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 110/88 Ah |
|---|---|
| Alternator | 12V, 90 Amp |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| 3 Point Linkage | CAT-II |
|---|---|
| Stay Bars | Adjustable |
| Hydraulic Lifting Capacity | 2000Kg |
| Auxiliary Hydraulic Circuit | 1DA+1SA |
| Lift Rods | Standard |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 65 |
|---|
Tyre
| Front | 9.5X24 |
|---|---|
| Rear | 16.9*28 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 2742 |
|---|---|
| Wheel Base (mm) | 2307 |
| Total Length (mm) | 3997 |
| Total Width (mm) | 1942 |
| Height (mm) Up to ROPS | 2620 |
| Min Ground Clearance (mm) | 293 |
| Front Track (mm) | 1672 |
| Rear Track (mm) | 1515 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Inbuilt in Front Weight |
| Front & Rear Weights with Std. Ballast | Front 31Kg * 6, Reach – 1X34 Kg on each tyre |
| Trailer Hitch | Swinging Drawbar |
| ROPS | Standard |
Optional Features
| Canopy | Optional |
|---|---|
| 2WD Variant | Yes with 7.5*6 Front Tyre |
| Tyre 4WD | 16.9X30 (Rear) |
