Features

Engine

In house powerful 3 Cylinder Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R Swift Shift Transmission

Jerk Free & Noise free Gear Shifting

Multiple tyre option

Radial & Bias Tyre suitable for durability and maneuverability

Reinforced Safety Features

Better comfort & safety during tough jobs

Technical Specifications

Engine

Engine Type 3 Cylinder Natural Aspirated Engine
HP Category 50
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 3067
Rated RPM 2100
Air Cleaner Dry Type with Clogging Sensor
Max Torque (Nm) 205 Nm
Exhaust Updraft/Downdraft
Muffler Under-hood



Transmission

Drive 2WD/4WD
Clutch Dual Clutch
Gearbox 8F+2R
Transmission Constant mesh/ Synchromesh (Optional)



Speed (Forward)

Maximum Speed (Km/Hr) 31.88 @ 2100 erpm
Minimum Speed (Km/Hr) 2.57 @ 2100 erpm



Brakes

Brakes Oil Immersed Brake
Type of Actuation Mechanical
Parking Brake Independent Type



Differential Lock

Differential Lock Mechanical, Foot Operated



PTO

PTO (RPM) 540
PTO (Actuation) Mechanical



Steering

Steering Power



Electrical

Battery 12V, 88Ah
Alternator 12V, 36Amp
Seven Pin Trailer Socket Output 12V



Hydraulics

3 Point Linkage CAT-II
Stay Bars Adjustable
Hydraulic Lifting Capacity 1600kg
Auxiliary Hydraulic Circuit 2DA/1SA-1DA (Optional)



Safety Switch

PTO Safety Switch Standard
Neutral Safety Switch Standard



Capacity (Ltrs) (+/- 5%)

Fuel Tank (Ltr.) 65



Turning Radius

Without Brakes (m) 4.7



Tyre

Front 9.5 – 20
Rear 13.6 – 28



Dimention & Weight (+/- 5%)

Weight (kg) 2780
Wheel Base (mm) 2200
Total Length (mm) 3945
Total Width (mm) 1789
Height (mm) Up to ROPS 2461
Min. Ground Clearance (mm) 276
Front Track (mm) 1295-1650
Rear Track (mm 1420-1880



Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard, Inbuilt in Front weights
Front & Rear Weights with std. Ballast Base Weight 72Kg + Front 30*2+25*4
Rear 2 x 34Kg (one on each wheel)
Trailer Hitch Swinging Bar (Standard),
Clevis Hitch (Optional)



Optional Features

Tyres 4WD
Front Tyre: 9.5×20 | Rear Tyre: 14.9×28
Front Tyre: 250/85R20 | Rear Tyre: 340/85R28
2WD
Front Tyre: 6×16 | Rear Tyre: 14.9×28
Front Tyre: 6×16 | Rear Tyre: 340/85R28
Cabin Optional
Front Mud Guard Optiona
Loader Optional
Canopy Optional
Synchromesh Gear Shifting Optional



*Data and specifications are subject to change without any advance notice due to continuous product improvement and development. All Dimensions are with standard tyres.

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
