Features

Engine

In house Powerful 3 Cylinder Engine

Swift Shift 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Swift and easy loader operations

Parallelogram Loader Option

For comfortable operations under tough weather conditions

Integrated Safety HVAC Cabin (Optional)

Technical Specifications

Engine

Engine Type 3 Cylinder Turbocharged with Intercooler
HP Category 60
No. of Cylinders 3
Aspiration Turbo Charged
Cubic Capacity (cc) 2780
Rated RPM 2100
Air Cleaner Dry Type
Max Torque (Nm) 230Nm @ 1300 erpm
Exhaust Upward Exhaust
Muffler Under-hood



Transmission

Drive 4WD
Clutch Dual Clutch, Dry Friction Plate
Gearbox 8F+2R
Front Axle 2WD/4WD
Transmission Swift Shift



Speed (Forward)

Maximum Speed (Km/Hr) 32.79 @ 2100 erpm
Minimum Speed (Km/Hr) 2.50@ 2100 erpm (Varies with tyres)



Brakes

Brakes Oil Immersed Brake
Type of Actuation Mechanical (Ind)
Parking Brake Independent Type



Differential Lock

Differential Lock Mechanical, Foot Operated



PTO

PTO (RPM) 540 @1680 erpm
PTO (Actuation) Mechanical



Steering

Steering Power

Electrical

Battery 12V, 88Ah
Alternator 12V, 36Amp
Seven Pin Trailer Socket Output 12V



Hydraulics

3 Point Linkage CAT-II
Stay Bars Adjustable
Hydraulic Lifting Capacity 2000
Auxiliary Hydraulic Circuit 2DA/ 1SA+1DA (Optional)
Lift Rods Adjustable



Safety Switch

Clutch Safety Switch Standard
PTO Safety Switch Standard
Neutral Safety Switch Standard



Capacity (Ltrs) (+/- 5%)

Fuel Tank (Ltr.) 65



Tyre

Front 9.50×24
Rear 16.9×28



Dimention & Weight (+/- 5%)

Weight (kg) 3155 (max)
Wheel Base (mm) 2350
Total Length (mm) 3980
Total Width (mm) 1790-1950
Height (mm) Up to ROPS 2650
Min. Ground Clearance (mm) 360
Front Track (mm) 1295-1650
Rear Track (mm) 1420-1880



Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard, Inbuilt in Front weights
Front Weights with std. Ballast Front Weight 30*2+25*4 (4WD)
Front Weight 51+6*29 (2WD)
Trailer Hitch Swinging Draw Bar



Optional Features

Cabin Optional
Tyre Front Tyre:9.5×24 | Rear Tyre:16.9×28
                                       2WD Front Tyre:7.5×16 | Rear Tyre:16.9×28
                                       2WD Front Tyre:7.5×16 | Rear Tyre:16.9×28



*Data and specifications are subject to change without any advance notice due to continuous product improvement and development. All Dimensions are with standard tyres.

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
