Features

Engine

Agile 4 Cylinder Engine

Constant Mesh 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Swift and easy loader operations

Parallelogram Loader Option

For comfortable operations under tough weather conditions

Integrated Safety HVAC Cabin (Optional)

Technical Specifications

Engine

HP Category 75
Emission Stage2 / Stage3
No. of Cylinders 4
Aspiration Turbo Charged
Cubic Capacity (cc) 3707
Rated RPM 2200/2000
Air Cleaner Dry Air Cleaner
Cold Start Standard
Max Torque (Nm) 278 Nm @1200 | 289 Nm @1300
Exhaust Upward
Muffler Under-hood



Transmission

Drive 4WD
Clutch Dual Clutch, Dry Friction Plate
Gearbox 8F+2R
Front Axle 4WD
Transmission Constant Mesh



Brakes

Brakes Oil Immersed Brake
Type of Actuation Mechanical
Parking Brake Independent Type



Speed (Forward)

Maximum Speed (Km/Hr) 36.46 @ 2200 erpm
Minimum Speed (Km/Hr) 1.95 @ 2200 erpm



PTO

PTO (RPM) 540@1680
PTO (Actuation) Mechanical



Differential Lock

Differential Lock Mechanical, Foot Operated



Steering

Steering Power

Hydraulics

3 Point Linkage CAT-II
Hydraulic Lifting Capacity 2000 Kg
Auxiliary Hydraulic Circuit 2DA/ 1SA+1DA

Electrical

Battery 12V, 110 AH
Alternator 12V, 36Amps
Seven Pin Trailer Socket Output 12V



Safety Switch

Neutral Safety Switch Standard



Capacity (Ltrs) (+/- 5%)

Fuel Tank (Ltr)

65

Tyre

Front 11.2 x24
Rear 16.9 x30



Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard, Inbuilt in Front weights



Dimention & Weight (+/- 5%)

Weight (kg) 3120
Wheel Base (mm) 2310
Total Length (mm) 4190
Total Width (mm) 1980
Height (mm) Up to ROPS 2710
Min. Ground Clearance (mm) 400
Front Track (mm) 1670
Rear Track (mm) 1500



Optional Features

Canopy Optional
30*2+25*4 Front Weights Optional
Tyre Front Tyre: 7.5×16 | Rear Tyre: 16.9×30



*Data and specifications are subject to change without any advance notice due to continuous product improvement and development. All Dimensions are with standard tyres.

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
