Features

Engine

In house Power Packed Engine

Less chances of outbreak in tough condiitions

Reliable Mechanical Tractor

Headlamp

Twin Projector Headlamps, better visibility in night

Multiple Tyre Options

Suitable for any teraain i.e Grass application, Paddy application, Industrial application

Reinforced Safety Features

Better comfort & safety during tough jobs

Technical Specifications

Engine

Engine Type MHI Engine
HP Category 26
No. of Cylinders 3
Aspiration Natural
Cubic Capacity (cc) 1318
Rated RPM 2700
Air Cleaner Dry Type with Clogging Sensor
Cold Start Standard
Max Torque (Nm) 76.3 Nm
Exhaust Downdraft Exhaust
Muffler Under-hood

Transmission

Drive 4WD
Clutch Single Clutch
Gearbox 6F+2R
Front Axle 4WD
Transmission Sliding Mesh



Speed (Forward)

Maximum Speed (Km/Hr) 15.58 @ 2700 erpm
Minimum Speed (Km/Hr) 1.67 @ 2700 erpm
Speeds may vary with other tyres



Brakes

Brakes Oil Immersed Brakes
Type of Actuation Mechanical
Parking Brake Independent



Differential Lock

Differential Lock Mechanical, Foot Operated



PTO

PTO (RPM) 540/1000
PTO (Actuation) Mechanical



Steering

Steering Power

Electrical

Battery 12V, 65Ah
Alternator 12V, 42Amp
Seven Pin Trailer Socket Output 12V



Hydraulics

3 Point Linkage Cat 1-N
Stay Bars Anchor Chain
Hydraulic Lifting Capacity 600Kg
Auxiliary Hydraulic Circuit 1DA



Safety Switch

Clutch Safety Switch Standard
PTO Safety Switch Standard
Neutral Safety Switch Standard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Ltr) 26.5

Turning Radius

Without Brakes (m) 3.1



Tyre

Front 6.00 – 12
Rear 8.30 – 20



Dimention & Weight (+/- 5%)

Weight (kg) 1020
Wheel Base (mm) 1560
Total Length (mm) 2760
Total Width (mm) 1075
Height (mm) Up to ROPS 1955
Min. Ground Clearance (mm) 240
Front Track (mm) 885
Rear Track (mm) 835



Others

Fuel Indicator Gauge Standard
Front Tow Hook Standard
Front & Rear Weights with std. Ballast Front weights – 15 x 2
Trailer Hitch 1. Swinging Bar (Optional)
  2. Clevis Hitch (Standard)
Roll Over Protection Standard
Canopy Optional

Optional Features

Tyres TURF
Front Tyre: 23×8.50 – 12
Rear Tyre: 33×15.50 – 16.5
INDUSTRIAL
Front Tyre: 23×8.50 – 12
Rear Tyre: 33×15.50 – 16.5
AGRI
Front Tyre: 6×12
Rear Tyre: 8.3×20
Front Tyre: 7×14
Rear Tyre: 8.3×24
RADIAL
Front Tyre: 6.5/80-12
Rear Tyre: 280/70 R18
GALAXY PRO
Front Tyre: 220/55 R12
Rear Tyre: 280/70 R16
Front End Loader Optional



*Data and specifications are subject to change without any advance notice due to continuous product improvement and development. All Dimensions are with standard tyres.

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Rotary Slasher
