Features
Engine
4 CYLINDER, NATURAL ASPIRATED ENGINE
Hydraulics
HEAVY-LIFTING CAPACITY
Transmission
SYNCHROMESH SHUTTLE TRANSMISSION WITH
CREEPER
Compact Design
ORCHARD/VINEYARD
FARMING SPECIALIST
Technical Specifications
Engine
| Engine Type | 4 Cylinder, Natural Aspirated Engine |
| HP Category | 60 |
| No. of Cylinder | 4 |
| Aspiration | Natural |
| Cubic Capacity | 3707 cc |
| Rated RPM | 2200 |
| Air Cleaner | Dry Air Cleaner with Clogging Sensor |
| Cold Start | Yes |
| Max Torque (Nm) | 230@1200 RPM |
| Exhaust | Underhood Downdraft Towards the Floor |
Transmission
| Clutch | Double Clutch |
| Gearbox | 12F+12R |
| Front Axle | 4 WD |
| Transmission | Synchromesh Shuttle Transmission with Creeper |
Speed (Forward)
| Minimum Speed (Km/hr) | 0.46@2000 erpm |
| Maximum Speed (Km/hr) | 28.27@2200 erpm |
Brakes
| Brakes | Oil Immersed |
| Type of Actuation | Mechanical |
| Parking Brake | Independent Type |
DIFFERENTIAL LOCK
| Differential Lock | Yes, Foot Operated |
PTO
| PTO (rpm) | 540 & 540E |
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
ELECTRICALS
| Battery | 12V, 88 Ah |
| Alternator | 12V, 85 Amp |
| Seven Pin Trailer Socket | Yes |
Hydraulics
| 3 Point Linkage | CAT – II |
| Stay Bars | Standard |
| Auxiliary Hydraulic Circuit | 2DA/2SA/3DA (Optional) |
| Hydraulic Lifting Capacity (Kg) | 2500 Kg |
SAFETY SWITCH
| Clutch Safety Switch | Standard |
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Ltr.) | 73 L |
TURNING RADIUS
| Without Brakes (m) | 4.58 |
Tyre
| Front | 8 – 18 |
| Rear | 14.9-24 |
OVERALL DIMENSIONS
| Weight (Kg) | 2735 |
| Overall Length (mm) | 4252 |
| Overall Width (mm) | 1475-1606 |
| Overall Height (mm) | 2630 |
| Wheel Base (mm) | 2307 |
| Min. Ground Clearance (mm) | 256 |
| Front Wheel Track Agri (mm) | 1150-1606 |
| Rear Wheel Track Agri (mm) | 1082-1213 |
Others
| Fuel Indicator Gauge | Standard |
| Front Tow Hook | Standard, Inbuilt in Front Weight |
| Front & Rear Weights with Std. Ballast | Front-72 Kg + 6×31 Kg Front Removal Weight. Rear 1*30 Kg At Each Wheel |
| Trailer Hitch | Swinging Drawbar |
| ROPS | Optional |
OPTIONAL FEATURES
|
Tyres 4WD
2WD
|
1) Front Tyre: 260/70R16 | Rear Tyre: 360/70R24 2) Front Tyre: 280/70R18 | Rear Tyre: 360/70R28 3) Front Tyre: 280/70R18 | Rear Tyre: 420/70R24 4) Front Tyre: 6.5×16 | Rear Tyre: 360/70/R28 5) Front Tyre: 6.0×16 | Rear Tyre: 360/70/R24 6) Front Tyre: 6.5×16 | Rear Tyre: 420/70R24 |
| Cabin | HVAC |
| Front Mudguard | Standard |
