Features
Engine
Three Cylinder Natural Aspirated Engine
Lifting Capacity
Heavy Duty 1600 Kg Lifting Capacity
8F+2R constant Mesh Transmission
Jerk Free & Noise free Gear Shifting
Reinforced Safety Features
Metalic Body, Better comfort & safety during tough jobs
Variants
Heavy Duty 4WD
Pneumonic
Suitable For Paddy Application
Technical Specifications
Engine
| Engine Type | Three Cylinder Natural Aspirated Engine |
|---|---|
| HP Category | 50 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 3067 |
| Rated RPM | 2100 |
| Air cleaner | Dry air cleaner with clogging sensor |
| Cold Start | Standard |
| Max Torque (nm) (+/-5%) | 205 (±5%) @ 1200 ± 100 |
| Exhaust | Updraft |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Dual Clutch |
| Gearbox | 8F+2R |
| Front Axle | Dana Axle |
| Transmission | Constant Mesh |
Speed (Forward)
| Min Speed(km/h) | 2.46 |
|---|---|
| Max Speed(km/h) | 32.44 |
Brakes
| Brakes | Oil Immersed Brake |
|---|---|
| Type of actuation | Mechanical |
| Hand Brake | Yes |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| Power Take Off (RPM) | 540 |
|---|---|
| Power Take Off (Actuation) | Mechanical |
Steering
| Steering | Power Steering |
|---|
Electrical
| Battery | 12V, 88 Ah |
|---|---|
| Alternator | 36 AMP, 12V |
| Seven Pin Trailer Socket | Yes |
Hydraulics
| 3 Point Linkage | CAT-II |
|---|---|
| Lifting Capacity | 1600Kg |
| Auxiliary Hydraulic Circuit | 1DA |
Safety Switch
| Clutch Safety Switch | Yes |
|---|
Capacity (Ltrs) (+/- 5%)
| Fuel Tank | 55 |
|---|
TURNING CIRCLE IN (M)
| Without Brakes | 6.9 |
|---|
Tyre
| Front | 8-18 |
|---|---|
| Rear | 14.9-28 |
Dimention & Weight (+/- 5%)
| Gross Weight(kg) | 2019 (Unballast Weight) |
|---|---|
| Wheel Base (mm) | 2108 |
| Total Length (mm) | 3876 |
| Total Width (mm) | 1800 |
| Height (mm) (upto Exhaust Pipe) | 2281 |
| Ground Clearance (mm) min | 382 |
Others
| Fuel Indicator Gauge | Yes |
|---|---|
| Front Tow Hook | Yes, inbuilt in front weight |
| Front & rear weights with std. Ballast | Base Weight 72Kg+Front 6X31 Kg Rear 1X34 Kg on each wheel |
| Trailer Hitch | Auto Trailer Hitch |
