Features

Engine

Three Cylinder Natural Aspirated Engine

Lifting Capacity

Heavy Duty 650 Kg Lifting Capacity

6F+2R constant Mesh Transmission

Jerk Free & Noise free Gear Shifting

Reinforced Safety Features

Metalic Body, Better comfort & safety during tough jobs

Variants

Heavy Duty 4WD

Technical Specifications

Engine

Engine TypeITL
HP Category22
No. of Cylinders3
AspirationNatural
Cubic Capacity (cc)979
Rated RPM (+/-25mm)3050
Air cleanerOil Bath Type
ExhaustHorizontal

Transmission

Drive4WD
ClutchSingle Clutch
Gearbox6 Forward + 2 Reverse
Front Axle4WD
TransmissionSliding Mesh

Speed (Forward)

Maximum Speed (Km/Hr)21.33
Minimum Speed (Km/Hr)1.71
Driver SeatAdjustable

Brakes

BrakesDry
Type of actuationMechanical

Differential Lock

Differential LockYes, Foot Operated

PTO

PTO540/540E
PTO (Actuation)Mechanical

Steering

SteeringMechanical

Electrical

Battery12V, 50 Ah
Alternator12V
Seven Pin Trailer SocketStandard

Hydraulics

3 Point LinkageCat 1-N
Draft ControlYes
Hydraulic Lifting Capacity650Kg
Lift RodsStandard

Safety Switch

Clutch Safety SwitchStandard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)20

Turning Radius

Without brakes (m) as per standard tyres2.1(RHS) 2.3(LHS)

Tyre

Front5*12
Rear8*18

Dimention & Weight (+/- 5%)

Weight (Kg)850
Wheel Base (mm)1420
Total Length (mm)2540
Total Width (mm)970
Height (mm) Up to ROPS1225
Min Ground Clearance (mm)180
Track width Front (mm)905
Track width Rear (mm)730 (Std), 860

Others

Fuel Indicator GaugeStandard
Front Tow HookStandard
Front Weights30 Kg (Optional)

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher

Paddy filed
