Features

Engine

Three Cylinder Natural Aspirated Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R constant Mesh Transmission

Jerk Free & Noise free Gear Shifting

Reinforced Safety Features

Metalic Body, Better comfort & safety during tough jobs

Variants

Heavy Duty 4WD

Technical Specifications

Engine

Engine Type3- Cyl. Mitsubishi Engine
HP Category26
No. of Cylinders3
AspirationNatural
Cubic Capacity (cc)1318
Rated RPM2700
Air cleanerDry air cleaner with clogging sensor
Cold StartStandard
Max Torque (nm)75.2/2200
ExhaustHorizontal

Transmission

Drive4WD
ClutchSingle Clutch
Gearbox6 Forward + 2 Reverse
Front Axle4WD
TransmissionSliding Mesh

Speed (Forward)

Maximum Speed (Km/Hr)17.97
Minimum Speed (Km/Hr)1.98
Driver SeatAdjustable

Brakes

BrakesOil Immersed Brakes
Type of actuationMechanical
Parking BrakeIndependent

Differential Lock

Differential LockYes, Foot Operated

PTO

PTO540/540 E – 540 @ 2651 & 540E @ 2152
PTO (Actuation)Mechanical

Steering

SteeringPower Steering

Electrical

Battery12V, 65Ah
Alternator12V
Seven Pin Trailer SocketStandard

Hydraulics

3 Point LinkageCat-I
Draft ControlYes
Hydraulic Lifting Capacity600Kg
Auxiliary Hydraulic Circuit1SA

Safety Switch

Clutch Safety SwitchStandard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)30

Turning Radius

Without brakes (m) as per standard tyres2.1(RHS) 2.3(LHS)

Tyre

Front6X12
Rear8.3*20

Dimention & Weight (+/- 5%)

Weight (Kg)910
Wheel Base (mm)1565
Total Length (mm)2705
Total Width (mm)1070
Height (mm) Up to ROPS1300
Min Ground Clearance (mm)250
Front Track (mm)894
Rear Track (mm)825

Others

Fuel Indicator GaugeStandard
Front Tow HookStandard
Front Weights30 Kg
Trailer hitchStandard

Optional Features

TyresTURF TYRES:
Front Tyre – 23×8.50-12
Rear Tyre – 33×15.50-16.5
INDUSTRIAL TYRES:
Front Tyre- 23×8.50-12
Rear Tyre- 33×15.50-16.5

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher

Paddy filed
