Features

Engine

Agile 4 Cylinder Engine

Constant Mesh 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty 2000Kg Lifting Capacity

Circuit

1SA/1DA Auxiliary Hydraulic Circuit

Option Available

Available in Canopy/ ROPS

Technical Specifications

Engine

Engine Type 4100FLT
HP Category 75
No. of Cylinders 4
Aspiration Turbo Charged
Bore/Stroke(mm) 00/118
Cubic Capacity (cc) 3707
Rated RPM (+/-25mm) 2200
Air Cleaner Dry Type
Max Torque (Nm) @ RPM 246.43 @ 1201
Exhaust Updraft (Elliptical)

Transmission

Drive 2WD
Clutch Dual, Dry Friction Plate
Gearbox 8F+2R
Transmission Constant Mesh

Speed (Forward)

Min Speed(km/h) 3.03
Max Speed(km/h) 35.75
Driver Seat Adjustable

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical (Ind)
Hand Brake Yes

Differential Lock

Differential Lock (mechanical) Yes

Power Take Off

Power Take off (RPM) 540 PTO rpm @ 1680 erpm
Power Take off (Actuation) Type 1 Independent (Mechanical)

Steering

Steering Power Steering

Electrical

Battery 12v Dc Electrical
Alternator 12V, 36 AMP
Seven Pin Trailer Socket Yes

Hydraulics

Position Control Yes
Automatic Draft Control Yes
3 Point Linkage CAT II
Lifting Capacity 2000Kg
Auxiliary Hydraulic Circuit 1SA/1DA
No. of Spool Valves Floor Operated -3, Back Plate-2

Safety Switch

Neutral Safety Switch Yes
P.T.O Safety Switch Yes
Clutch Safety Switch Yes

Capacity (Ltrs) (+/- 5%)

Fuel Tank 62L
Engine Oil 12.5L
Hydraulic + Transmission 58L

Tyre

Option 1 Front:- 7.5-16
Rear:- 16.9-30

Dimention & Weight (+/- 5%)

Gross Weight (kg) 2610
Wheel Base (mm) 2210
Total Length (mm) 3740
Total Width (mm) 1910-2250
Height (mm) Up to ROPS 1770 (Steering), 2400 With Exhaust
Ground Clearance (mm) min 385
Front Track, (mm), min.-max. 1360-1710
Rear Track, (mm), min.-max. 1455-1785

Others

Fuel Indicator Gauge Yes
Registration Plate With Light Optional
Front Tow Hook Yes (Fixed)
Front & Rear Weights Front-72 Kg Base Wt+6×31,
Rear-1×34 On Each Wheel
Drawbar Linkage & Swinging Drawbar
ROPS Optional
Canopy Optional

Optional Features

Trailer Brake Optional
2WD Variant Yes

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
