Features

Engine

In house Powerful 110 HP 4 Cylinder Engine

Lifting Capacity

Heavy Duty 4500 Kg Lifting Capacity

Option Available

Available in Cabin/ ROPS

Circuit

3SA/ 3DA Auxiliary Hydraulic Circuit

Technical Specifications

Engine

Engine Type110 HP Powerful 4 Cylinder Engine
HP Category110
No. of Cylinders4
Displacement (ltr)4127
AspirationTurbo charged with CAC (TCIC)
Bore/Stroke (mm)105/118
Air cleanerThree stage Dry Air Type

Transmission

Drive4WD
ClutchDouble Clutch
Gearbox24F + 24R
TransmissionSynchromesh

Speed (Forward)

Maximum Speed (Km/Hr)36.58 @ 2200 RPM
Minimum Speed (Km/Hr)0.5 @ 2200 RPM
Driver SeatMechanical Suspension

Brakes

BrakesOil Immersed Brakes
Type of actuationHydraulically Assisted
Parking BrakeIndependent
Trailer BrakeHTB

Differential Lock

Differential LockStandard (Electrical Switch Operated)

PTO

PTO (RPM)540/540E
PTO (Actuation)Mechanical

Steering

SteeringPower

Electrical

Battery12V, 110Ah
Alternator12V, 90Amp
Seven Pin Trailer SocketStandard

Hydraulics

Position ControlStandard
Automatic Draft ControlStandard
3 Point LinkageCat-II
Lifting Capacity4500Kg
Auxiliary Hydraulic Circuit2DA / 2SA + 1DA (Detent & Float type)

Safety Switch

Neutral Safety SwitchStandard
P.T.O Safety SwitchStandard
Clutch Safety SwitchStandard

Capacity (Ltrs) (+/- 5%) Approx

Fuel Tank (Lit)117
Eng Oil (Ltr)11.75

Tyre

Front380/85R24
Rear460/85R34

Dimention & Weight (+/- 5%)

Gross Weight(kg)4250 (With Std. Ballast)
Wheel Base (mm)2376
Total Length (mm)4045
Total Width (mm)2225
Height (mm) Up to ROPS2968
Min Ground Clearance (mm)488
Front Track (mm) (Standard)1762
Rear Track (mm) (Standard)1724

Others

Fuel Indicator GaugeStandard
Registration Plate with LightStandard
Front Tow HookStandard
Front & Rear WeightsFront 31×10+72Kg base weight Rear 2×40 Kg
DrawbarStandard
ROPSStandard
CanopyStandard

Optional Features

CanopyStandard
TyresFront: 12.4 – 28 (TR – 171)
Rear: 16.9 – 38 (TR – 171)

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
