Features

Engine

In house powerful 3 Cylinder Engine

Lifting Capacity

Heavy Duty 1600 Kg Lifting Capacity

8F+2R Swift Shift Transmission

Jerk Free & Noise free Gear Shifting

Multiple tyre option

Radial & Bias Tyre suitable for durability and maneuverability

Reinforced Safety Features

Better comfort & safety during tough jobs

Technical Specifications

Engine

Engine TypeThree Cylinder Natural Aspirated Engine
HP Category50
No. of Cylinders3
AspirationNatural
Cubic Capacity (cc)3067
Rated RPM2100
Air cleanerDry Air Cleaner with Clogging sensor
Cold StartStandard
Max Torque (nm) (+/-5%)205 @ 1200 ± 100RPM
ExhaustUnderhood Downdraft Silencer Underhood Upward

Transmission

Drive2WD/4WD
ClutchDual Clutch
Gearbox8F+2R
Front Axle4WD
TransmissionSwift Shift

Speed (Forward)

Maximum Speed (Km/Hr)29.94@2100
Minimum Speed (Km/Hr)2.27@2100

Brakes

BrakesOil Immersed Brakes
Type of actuationMechanical
Parking BrakeIndependent

Differential Lock

Differential LockYes, Foot Operated

PTO

PTO (RPM)540
PTO (Actuation)Mechanical

Steering

SteeringPower

Electrical

Battery12V, 88 Ah
Alternator12V, 90 Amp
Seven Pin Trailer SocketStandard

Hydraulics

3 Point LinkageCAT-II
Stay BarsAdjustable
Hydraulic Lifting Capacity1600 kg
Auxiliary Hydraulic Circuit2DA
Lift RodsStandard

Safety Switch

Neutral Safety SwitchStandard
Clutch Safety SwitchStandard
Neutral Safety SwitchStandard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)65

Turning Radius

Without Brakes (m)3.7

Tyre

Front9.5-20
Rear13.6-28

Dimention & Weight (+/- 5%)

Weight (Kg)2780
Wheel Base (mm)2175
Total Length (mm)3936
Total Width (mm)1785
Height (mm) Up to ROPS2488
Min Ground Clearance (mm)293
Front Track (mm)1535
Rear Track (mm)1420

Others

Fuel Indicator GaugeStandard
Front Tow HookInbuilt in Front Weight
Front & Rear Weights with Std. Ballast30X2+25X4
Trailer HitchSwinging Drawbar
ROPSStandard

Optional Features

Tyres (Radial Tyre)Front 250/85R20, Rear 340/85R28
CabinOptional
2WD Front Tyre7.5-16

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
