Features

Engine

Agile 4 Cylinder Engine

Constant Mesh 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Swift and easy loader operations

Parallelogram Loader Option

For comfortable operations under tough weather conditions

Integrated Safety HVAC Cabin (Optional)

Technical Specifications

Engine

Engine Type4 Cylinder Turbo Charged Engine
HP Category75
No. of Cylinders4
AspirationTurbo Charged
Cubic Capacity (cc)3707
Rated RPM (+/-mm)2200
Air cleanerDry Air Cleaner with Clogging Sensor
Cold StartStandard
Max Torque (nm) (+/- 5%)278 @ 1200 ERPM
ExhaustUnderhood Downdraft Silencer Underhood Upward

Transmission

Drive4WD
ClutchDual Clutch
Gearbox12F+12R
TransmissionSynchronmesh

Speed (Forward)

Maximum Speed (Km/Hr)33.73 @ 2200
Minimum Speed (Km/Hr)1.69 @ 2200

Brakes

BrakesOil Immersed Brakes
Type of ActuationMechanical
Parking BrakeIndependent Type

Differential Lock

Differential LockStandard, Foot Operated

PTO

PTO (RPM)540/540E
PTO (Actuation)Mechanical

Steering

SteeringPower

Electrical

Battery12V, 88 AH or 110 AH
Alternator12V, 90Amps
Seven Pin Trailer SocketStandard

Hydraulics

3 Point LinkageCAT-II
Stay BarsAdjustable
Hydraulic Lifting Capacity2500Kg (3000Kg Optional)
Auxiliary Hydraulic Circuit2DA/2SA
Lift RodsStandard

Safety Switch

Clutch Safety SwitchStandard
PTO Safety SwitchStandard
Neutral Safety SwitchStandard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)64

Turning Radius

Without Brakes (m)LHS: 6.9 , RHS: 6.53

Tyre

Front11.2-24
Rear16.9-30

Dimention & Weight (+/- 5%)

Weight (Kg)3180
Wheel Base (mm)2350
Total Length (mm)4330
Total Width (mm)1910
Height (mm) Up to ROPS2775
Min Ground Clearance (mm)385
Front Track (mm)1615-1910
Rear Track (mm)1515-1805

Others

Fuel Indicator GaugeStandard
Front Tow HookStandard, Inbuilt in Front Weight
Trailer HitchSwinging Drawbar
ROPSStandard

Optional Features

CanopyHVAC/Heater (Optional)
Front MudguardStandard
Trailer BrakeHTB/ATB
TyreFront : 12.4X24, Rear: 18.4X30
Rear Optional: 13.6X38
2WDFront : 7.5X16,  Rear 16.9X30
Radial280/85R24, 420/85R30

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
