Features

Engine

Agile 4 Cylinder Engine

Constant Mesh 8F+2R Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Swift and easy loader operations

Parallelogram Loader Option

For comfortable operations under tough weather conditions

Integrated Safety HVAC Cabin (Optional)

Technical Specifications

Engine

Engine Type4100FLT
HP Category75
No. of Cylinders4
AspirationTurbo Charged
Cubic Capacity (cc)3707
Rated RPM (+/-mm)2200
Air cleanerDry Type with Clogging Sensor
Cold StartStandard
Max Torque (nm) (+/- 5%)278 @ 1300ERPM
ExhaustElliptical Upward

Transmission

Drive4WD
ClutchDual Clutch
Gearbox8F+2R
TransmissionSwift Shift

Speed (Forward)

Maximum Speed (Km/Hr)36.46 @ 2200
Minimum Speed (Km/Hr)1.95 @ 2200

Brakes

BrakesOil Immersed Brakes
Type of actuationMechanical
Parking BrakeIndependent

Differential Lock

Differential LockStandard, Foot Operated

PTO

PTO (RPM)540
PTO (Actuation)Mechanical

Steering

SteeringPower

Electrical

Battery12V, 110/88 Ah
Alternator12V, 36Amps
Seven Pin Trailer SocketStandard

Hydraulics

3 Point LinkageCAT-II
Stay BarsAdjustable
Hydraulic Lifting Capacity2500Kg
Auxiliary Hydraulic Circuit1DA+1SA
Lift RodsStandard

Safety Switch

Neutral Safety SwitchStandard
Clutch Safety SwitchStandard
Neutral Safety SwitchStandard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit)65

Tyre

Front11.2-24
Rear16.9-30

Dimention & Weight (+/- 5%)

Unballast Weight2742
Wheel Base (mm)2307
Total Length (mm)3997
Total Width (mm)1942
Height (mm) Up to ROPS2620
Min Ground Clearance (mm)293
Front Track (mm) (Standard)1672
Rear Track (mm) (Standard)1515

Others

Fuel Indicator GaugeStandard
Front Tow HookStandard, Inbuilt in Front Weight
Front & Rear Weights with Std. BallastFront- 2X30Kg, 4X25, Rear- 1X34 Kg
Trailer HitchSwinging Drawbar
ROPSStandard

Optional Features

CanopyOptional
2WD VariantStandard
Tyre 2WDFront: 7.5X16

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
