Features

Engine

Powerful Agile High Backup Torque Engine

8F+2R Swift Shift Transmission

Jerk Free & Noise free Gear Shifting

Lifting Capacity

Heavy Duty Lifting Capacity

Attachment

Easy front and loader attachment

Variants

Heavy Duty 2WD/4WD

Technical Specifications

Engine

Engine Type 3100 FLS with coldstart
HP Category 45
Aspiration Natural
Cubic Capacity (cc) 2780
Rated rpm 2000
Aircleaner Dry Air Cleaner with Clogging sensor
Max Torque (nm) 174 (+/-5%) @1200RPM (+/-100)
Exhaust Updraft Upward

Transmission

Drive 2WD
Clutch Dual Clutch
Gearbox 8F+2R
Front Axle 2WD
Transmission Constant Mesh

Speed (Forward)

Maximum Speed (Km/Hr) 31.74@2000
Minimum Speed (Km/Hr) 2.25@2000

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical
Parking Brake Standard

Differential Lock

Differential Lock Mechanical

PTO

PTO (RPM) 540
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 88 Ah
Alternator 12V, 36Amps
Seven Pin Trailer Socket Yes

Hydraulics

3 Point Linkage CAT-II
Stay Bars Adjustable
Hydraulic Lifting Capacity 1200Kg
Auxiliary Hydraulic Circuit 1SA + 2DA
Lift Rods Yes

Safety Switch

Neutral Safety Switch Yes

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 55
Engine Oil (Lit) 8.2

Turning Radius

Without Brakes (m) 3.7

Tyre

Front 6X16
Rear 13.6X28

Dimention & Weight (+/- 5%)

Weight (Kg)  2030
Wheel Base (mm) 1975
Total Length (mm) 3630
Total Width (mm) 1715
Height (mm) Up to Exhaust pipe 2310
Min Ground Clearance (mm) 390
Front Track (mm) 1315
Rear Track (mm) 1345

Others

Fuel Indicator Gauge Yes
Front Tow Hook Yes, inbuilt in front weight
Front & Rear Weights with Std. Ballast Base weight 54 kg & 1X34 kr Rear each wheel
Trailer Hitch Standard rear tow hook
Drawbar Swinging draw bar with Linkage cross baar

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer
