Features
Engine
Powerful 55 HP 3 Cylinder Engine
Lifting Capacity
Heavy Duty 2200 Kg Lifting Capacity
8F+2R constant Mesh Transmission
Jerk Free & Noise free Gear Shifting
Reinforced Safety Features
Metalic Body, Better comfort & safety during tough jobs
Variants
Heavy Duty 2WD/4WD
Technical Specifications
Engine
| Engine Type | Three Cylinder Turbo Charged |
|---|---|
| HP Category | 55 |
| No. of Cylinders | 3 |
| Aspiration | Turbo Charged |
| Cubic Capacity (cc) | 2780 |
| Rated RPM | 2100 |
| Air cleaner | Dry Air Cleaner with Clogging sensor |
| Cold Start | Standard |
| Max Torque (nm) (+/-5%) | 230 @ 1300 ERPM |
| Exhaust | Upward Draft |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Dual Clutch |
| Gearbox | 8F+2R |
| Front Axle | 4WD |
| Transmission | Constant Mesh with swift shift |
Speed (Forward)
| Maximum Speed (Km/Hr) | 33.62 |
|---|---|
| Minimum Speed (Km/Hr) | 2.57 |
Brakes
| Brakes |
5 Disc Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent Type |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| PTO (RPM) | 540 |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 88 Ah |
|---|---|
| Alternator |
12V, 36Amps |
| Seven Pin Trailer Socket | Standard |
Hydraulics
| 3 Point Linkage | CAT-II |
|---|---|
| Stay Bars | Floating Type |
| Auxiliary Hydraulic Circuit | 2DA (convertible type) |
| Lift Rods | Standard |
| LPM (Liter per minute) | 35 |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 65 |
|---|---|
| Engine oil (Ltr) | 9 |
| Transmission + Hydraulic oil (Ltr) | 60 |
Tyre
| Front | 9.5*24, 7.5*16 (2WD) |
|---|---|
| Rear | 16.9*28 |
Dimention & Weight (+/- 5%)
| Weight (Kg) (4WD/2WD) | 2700/2500 |
|---|---|
| Wheel Base (mm) (4WD/2WD) | 2300/2208 |
| Total Length (mm) | 3981 |
| Total Width (mm) | 1950 |
| Height (mm) Up to ROPS | 2250 |
| Min Ground Clearance (mm) | 360 |
| Front Track (mm) | 1326-1690 |
| Rear Track (mm) | 1420-1870 |
Others
| Trailer Hitch – option 1 | Fixed Trailer Hitch |
|---|---|
| Front Tow Hook | Standard |
| Front weight (2WD) | 72Kg + 6*31 |
| Front weight (4WD) | 72Kg + 4*31 |
| Drawbar | Standard |
| Safety Neutral Switch | Standard |
Optional Features
| Canopy | Optional |
|---|---|
| 2WD Front Tyre | 7.5-16 |
