Features

Engine

Turbo Charged with inter cooler engine

USP

Orchard / Vineyard Farming Specialist

Lifting Capacity

Heavy Duty Lifting Capacity

Renound gear box for better durability and comfort

Carraro Drive Line

For comfortable operations under tough weather conditions

HVAC / Heater Cabin (Optional)

Technical Specifications

Engine

Engine Type 4105 ELT, Turbo Charged with Inter Cooler Engine
HP Category 90
No. of Cylinders 4
Aspiration Turbo Charged
Cubic Capacity (cc) 4087
Rated RPM (+/-mm) 2000
Air cleaner Dry Type with Clogging Sensor
Cold Start Standard
Max Torque (nm) (+/- 5%) 360 @ 1300
Exhaust Underhood Downdraft towards the Floor

Transmission

Drive 4WD
Clutch Double Clutch
Gearbox 12F+12R
Front Axle 4WD
Transmission Synchromesh

Speed (Forward)

Maximum Speed (Km/Hr) 28.25 @ 2000
Minimum Speed (Km/Hr) 0.46 @ 2000

Brakes

Brakes Oil Immersed Brakes
Type of actuation Mechanical
Parking Brake Independent

Differential Lock

Differential Lock Standard, Foot Operated

PTO

PTO (RPM) 540/540E
PTO (Actuation) Mechanical

Steering

Steering Power

Electrical

Battery 12V, 85Ah
Alternator 12V, 90Amp
Seven Pin Trailer Socket Standard

Hydraulics

3 Point Linkage CAT-II
Stay Bars Standard
Hydraulic Lifting Capacity 2500Kg
Auxiliary Hydraulic Circuit 2DA/2SA
Lift Rods Standard

Safety Switch

Clutch Safety Switch Standard
PTO Safety Switch Standard
Neutral Safety Switch Standard

Capacity (Ltrs) (+/- 5%)

Fuel Tank (Lit) 73

Turning Radius

Without Brakes (m) 3.6

Tyre

Front 8-18
Rear 14.9-24

Dimention & Weight (+/- 5%)

Overall Length (mm) 4240
Overall Width (mm) 1475
Overall Height upto ROPS (mm) 2700
Wheel Base (mm) 2306
Min. Ground Clearance 265
Front Wheel Track Agri (mm) 1150
Rear Wheel Track Agri (mm) 1082
Flange to Flange Distance Front/Rear 1155mm/892mm

Others

Fuel Indicator Gauge Standard
Front Tow Hook Yes, Inbuilt in Front Weight
Front & Rear Weights with Std. Ballast Front-72 Kg base wt 6X31 Kg
Front Removal Weight. / Rear 2X30 Kg
Trailer Hitch Swinging Drawbar
ROPS Mid Mounted Foldable

Optional Features

Tyres Front – 210/95/R18, Rear – 360/70/R28
Front – 280/70R18, Rear – 360/70R28
Front – 260/70R16, Rear – 360/70R24
Cabin HVAC / Heater
Front Mudguard Standard
Trailer Brakes HTB
Front Tyre 2WD 6.5×16

Application

Rotavator

Front End Loader

Cultivator

Disc Harrow

Trailer

Planter

Rotary Slasher
