Features
Engine
In house Power Packed Engine
Less chances of outbreak in tough condiitions
Reliable Mechanical Tractor
Headlamp
Twin Projector Headlamps, better visibility in night
Multiple Tyre Options
Suitable for any teraain i.e Grass application, Paddy application, Industrial application
Reinforced Safety Features
Better comfort & safety during tough jobs
Technical Specifications
Engine
| Engine Type | Mitsubishi 3 Cylinder Engine |
|---|---|
| HP Category | 26 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 1318 |
| Rated RPM | 2700 |
| Air cleaner | Dry |
| Cold Start | Standard |
| Max Torque (nm) | 76.3 @ 2700 |
| Exhaust | Underhood Downdraft Silencer |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Single Clutch |
| Gearbox | 6F+2R |
| Front Axle | 4WD |
| Transmission | Sliding Mesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 14.04 @ 2700 |
|---|---|
| Minimum Speed (Km/Hr) | 1.50 @ 2700 |
Brakes
| Brakes | Oil Immersed Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| PTO | 540, 1000 |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power |
|---|
Electrical
| Battery | 12V, 65Ah |
|---|---|
| Type of Actuation | 12V, 42Amp |
| Parking Brake | Standard |
Hydraulics
| 3 Point Linkage | Cat-I |
|---|---|
| Stay Bars | Anchor Chain |
| Lifting Capacity | 600Kg |
| Auxiliary Hydraulic Circuit | 1DA/ 1SA (Optional) |
| Lift Rods | Standard |
| Flow(LPM) | 18 |
Safety Switch
| Clutch Safety Switch | Standard |
|---|---|
| PTO Safety Switch | Standard |
| Neutral Safety Switch | Standard |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 26.5 |
|---|
Turning Radius
| Without Brakes (m) | 2.3 |
|---|
Tyre
| Front | 6.00-12 |
|---|---|
| Rear | 8.30-20 |
Dimention & Weight (+/- 5%)
| Weight (Kg) | 960 |
|---|---|
| Wheel Base (mm) | 1560 |
| Total Length (mm) | 2725 |
| Total Width (mm) | 1058 |
| Height (mm) Up to ROPS | 2153 |
| Min Ground Clearance (mm) | 255 |
| Front Track (mm) | 894 |
| Rear Track (mm) | 825 |
Others
| Fuel Indicator Gauge | Standard |
|---|---|
| Front Tow Hook | Standard |
| Front & Rear Weights with Std. Ballast | Front weights-15×2 |
| Trailer Hitch | 1. Clevis Hitch 2. Swinging Drawbar (Optional) |
| Height (mm) Up to ROPS | 2153 |
| ROPS | Standard |
Optional Features
| Tyres | TURF TYRES: Front Tyre – 23×8.50-12 Rear Tyre – 33×15.50-16.5 INDUSTRIAL TYRES: Front Tyre- 23×8.50-12 Rear Tyre- 33×15.50-16.5 |
|---|
