Features

Engine
High Torque 4 Cylinder
Turbo Engine
Turbo Engine

Hydraulics
Advanced Hydraulic
3500Kg Lifting Capacity
3500Kg Lifting Capacity

Transmission
12F+12R Synchro
Shuttle Transmission
Shuttle Transmission

Comfort Package
Spacious operator area
Tiltable and telescopic
hydrostatic steering
Tiltable and telescopic
hydrostatic steering

REINFORCED SAFETY FEATURES
Eminent
Versatility,
Build & Style
Versatility,
Build & Style
Technical Specifications
Engine
Engine Type | Turbocharged intercooled engine |
HP Category | 107 |
No. of Cylinders | 4 |
Cubic Capacity (cc) | 4087 |
Rated RPM | 2200 |
Air Cleaner | 2 Stage Dry Air Filter with Dust Scavenging System |
Max Torque (Nm) | 420 Nm |
Transmission
Drive | 4WD |
Clutch | Double Clutch |
Gearbox | 12F+12R |
Transmission | Synchro Shuttle Transmission |
Speed (Forward)
Maximum Speed (Km/Hr) | 34.86 |
Minimum Speed (Km/Hr) | 1.67 |
Brakes
Brakes | Oil Immersed Brake |
Type of Actuation | Hydraulically assisted |
Parking Brake | Independent |
Differential Lock
Differential Lock | Yes |
PTO
PTO (RPM) | 540/540E 540/1000 (optional) |
PTO (Actuation) | Mechanical |
Steering
Steering | Tiltable & Telescopic Hydrostatic Steering |
Electrical
Battery | 12V, 110AH |
Alternator | 12V, 90Amp |
Seven pin trailer socket | Yes |
Hydraulics
3 Point Linkage | Quick Attach CAT-II |
Hydraulic Lifting Capacity | 3500 Kg |
Auxiliary Hydraulic Circuit | 2DA/2SA |
Safety Switch
Clutch Safety Switch | Yes |
PTO Safety Switch | Yes |
Neutral Safety Switch | Yes |
Capacity (Ltrs) (+/- 5%)
Fuel Tank (Ltr) | 117 |
TYRES
Front | 380/85R24 |
Rear | 460/85R34 |
DIMENSIONS & WEIGHT (+/-5%) kg
Weight (kg) | 4085 |
Wheel Base (mm) | 2375 |
Total Length (mm) | 4315 |
Total Width (mm) | 2255 |
Height (mm) up to Canopy | 2690 |
Min Ground Clearance (mm) | 470 |
OTHERS
Front Tow Hook | Yes, inbuilt in front weight |
Front & Rear Weights | Front : 72 +(31*8 ) Rear : 40X2 (rear wheels) |
Rear Hitch | Heavy Duty Ladder Hitch |
ROPS | Yes |
Canopy | Yes (Optional) |
OPTIONAL
Bias tyre | Front : 14.9 x 24 | Rear : 18.4 x 34 |
