Tractor Trailed Boom Sprayer
Tractor Mounted Boom Sprayer
Boom Sprayer is most suitable for uniform and effective spray over crops. This boom sprayer comes with high quality nozzle and imported pump for long life of sprayer.
Best quality material for long lasting life
Heavy Duty Robust frame
High quality nozzle to handle almost all types of liquid used for agriculture spraying
Hydraulic agitation for enhanced spray quality
Best class pump for better spray
Technical Specification (Tractor Mounted Boom Sprayer)
| Model | SLTMBS-20 | SLTMBS-400 | SLTMBS-600 |
| Tank Capacity (L) | 200 | 400 | 600 |
| Material | Polyethylene | ||
| Agitation | Jet | Hydraulic | |
| Level indicator | Graduated Transparent tube | Graduated circular dial |
Graduated circular dia
|
| Pump Type | Triplex plunger pumping unit (*Diaphragm Optional) | ||
| Pump Capacity (L/min) | 36 | 50 (*70 liter optional) | |
| Pump Working pressure (bars) | 40 | ||
| Pump Recommended working (bars) pressure |
1-10 | ||
| RPM | 900 | ||
| Boom Width (m) | 3-6 | 10 | |
| Height Adjustment (inches) |
Manually up to 24 (up to 72 optional) | ||
| Type | Multiple Angle yoga wet type Boom |
Wet Boom | |
| Actuation | Jerk Free Spring loaded, Auto centralized manual Boom |
Manual | |
| Nozzle spacing (cm) | 50 | ||
| Number of nozzles | 12 | 20 | |
| Working speed (km/hr) |
2-6 | ||
| Length x Width x Height (mm) |
762x1803x1473 | 1346x2235x1498 | 803x1220x1574 |
| Weight (Approx.)(kg) | 120 | 190 | 298 |
Technical Specification (Trailed Type Boom Sprayer)
| Model Name | TankCapacity (Ltrs.) | Spray Discharge Adjustment (ltrs.) | Anti Drip System | Per Day Working Capacity | Boom Size | No. of Nozzles | Nozzle Distance (mm) | Height Adjustment | Tractor(HP) |
|---|---|---|---|---|---|---|---|---|---|
| SL-TBS-2000 | 2000 | 73-115 | Yes | 35-50 hectares | 18m, Manual folding | 36 | 500 | 6-8 Feet | 90 |
