Features
Engine
In house powerful 3 Cylinder Engine
6F+2R Transmission
Jerk Free & Noise free Gear Shifting
HeadLamp
Twin Projector Headlamps, better visibility in Night
Multiple Tyre Options
Suitable for any terrain i.e Grass application, Paddy application, Industrial application
Reinforced Safety Features
Better comfort & safety during tough jobs
Technical Specifications
Engine
| Engine Type | Mitsubishi 3 Cylinder |
|---|---|
| HP Category | 20 |
| No. of Cylinders | 3 |
| Aspiration | Natural |
| Cubic Capacity (cc) | 952 |
| Rated RPM | 2700 |
| Air cleaner | Dry |
| Cold Start | Yes |
| Max Torque (nm) | 50 |
| Exhaust | Underhood Downdraft Silencer |
Transmission
| Drive | 4WD |
|---|---|
| Clutch | Single Clutch |
| Gearbox | 6F+2R |
| Front Axle | 4WD |
| Transmission | Sliding Mesh |
Speed (Forward)
| Maximum Speed (Km/Hr) | 15.26@2700 |
|---|---|
| Minimum Speed (Km/Hr) | 1.3@2700 |
Brakes
| Brakes | Dry Drum Brakes |
|---|---|
| Type of actuation | Mechanical |
| Parking Brake | Independent |
Differential Lock
| Differential Lock | Yes, Foot Operated |
|---|
PTO
| PTO (RPM) | 540, 540E, 1000* |
|---|---|
| PTO (Actuation) | Mechanical |
Steering
| Steering | Power Steering |
|---|
Electrical
| Battery | 12V, 65Ah |
|---|---|
| Alternator | 12V, 42Amp |
| Parking Brake | Yes |
Hydraulics
| 3 Point Linkage | CAT-I |
|---|---|
| Stay Bars | Anchor Chain |
| Auxiliary hydraulic circuit | 1DA/1SA (optional) |
| Lift rods | Yes |
| Lifting capacity | 500kg |
| Litre Per Minute (LPM) | 12 |
Safety Switch
| Clutch Safety Switch | Yes |
|---|---|
| PTO Safety Switch | Yes |
| Neutral Safety Switch | Yes |
Capacity (Ltrs) (+/- 5%)
| Fuel Tank (Lit) | 26.5 |
|---|
Turning Radius
| Without Brakes (m) | 2.3 |
|---|
Tyre
| Front | 5.00 – 12 |
|---|---|
| Rear | 8.00 – 18 |
Dimention & Weight (+/- 5%)
| Weight (Kg) (Unballast) | 885 |
|---|---|
| Wheel Base (mm) | 1420 |
| Total Length (mm) | 2710 |
| Total Width (mm) | 925 |
| Height (mm) Up to ROPS | 1925 |
| Min Ground Clearance (mm) | 220 |
| Front Track (mm) | 820 |
| Rear Track (mm) | 725 |
Others
| Fuel Indicator Gauge | Yes |
|---|---|
| Front Tow Hook | Yes |
| Front & rear weights with std. Ballast | Front weight – 2X15 Kg |
| Trailer Hitch | 1. Clevis Hitch 2. Swinging Drawbar (Optional) |
| ROPS | Yes |
Optional Features
| Tyres | TURF TYRES: Front Tyre – 23×8.50-12 Rear tyre – 33×15.50 – 16.5 INDUSTRIAL TYRES: Front tyre- 23×8.50-12 Rear tyre- 33×15.50-16.5 |
|---|
